10mm 4Pin RGB Mini IP20 COB LED Strip Connectors
#LED Strip ConnectorThese 10mm 4Pin RGB Mini IP20 COB LED Strip Connectors offer a compact solution for connecting RGB COB LED strips. With 4-pin connectivity for full-color control and an IP20 rating for dust protection, they are ideal for indoor lighting applications. Perfect for both residential and commercial projects, these connectors ensure smooth, vibrant lighting and easy installation.
#LED Strip Connector
Hippo-M MINI Series - 10mm 4Pin COB Strip Connector
This IP20-rated connector is designed to work with most COB and SMD LED strip lights, providing a versatile solution for creating
customized lighting designs with ease and flexibility.
- Reliable Connections: Pierce-to-contact technology ensures secure and stable connections.
- Quick Installation: No wire stripping needed, making setup faster and simpler.
- Customizable: Available with or without cables to suit various needs.
- Compact Design: Fits easily into tight spaces like aluminum channels, furniture grooves, and narrow gaps.
- Long-Lasting: Made from durable materials for extended performance.
- Sleek Aesthetic: Perfectly integrates into both modern and professional lighting setups.
- Wide Compatibility: Compatible with a variety of COB and SMD LED strips.
- Easy to Use: Plug-and-play functionality for both professionals and DIY enthusiasts.
- Cost-Effective: Reusable and easy to install, cutting down on time and maintenance costs.
- Versatile: Ideal for precise lighting in compact or hard-to-reach spaces.
| Model No. | 580# MN20-B10C-4P | 581# MN20-X10C-4P |
| Max Current | 3.5A | 3.5A |
| Rated Voltage | 0-36V | 0-36V |
| Ambient Temperature | -10℃ to 40℃ | -10℃ to 40℃ |
| Max Temperature Resistance | 80°C | 80°C |
| Flame Retardant Rating | Compliant with UL-94-V2 | Compliant with UL-94-V2 |
| Suitable Wire Cross Section | / (Strip to strip) | 0.35mm² (AWG 22) |
| Insulation Outer Diameter (OD) | / (Strip to strip) | < 1.6mm |
| Compatible LED Strip Specifications | 10mm 4Pin IP20 COB Strip Lights | 10mm 4Pin IP20 COB Strip Lights |
| Flexible LED Strip PCB Process | Optimal thickness 0.25mm to 0.35mm / Suitable for IP20 LED strips | Optimal thickness 0.25mm to 0.35mm / Suitable for IP20 LED strips |
| Model No. | 582# MN20-XB10C-4P/L15CM | 583# MN20-2XB10C-4P/L15CM |
| Max Current | 3.5A | 3.5A |
| Rated Voltage | 0-36V | 0-36V |
| Ambient Temperature | -10℃ to 40℃ | -10℃ to 40℃ |
| Max Temperature Resistance | 80°C | 80°C |
| Flame Retardant Rating | Compliant with UL-94-V2 | Compliant with UL-94-V2 |
| Suitable Wire Cross Section | / (Strip to strip) | 0.35mm² (AWG 22) |
| Insulation Outer Diameter (OD) | < 1.6mm | < 1.6mm |
| Compatible LED Strip Specifications | 10mm 4Pin IP20 COB Strip Lights | 10mm 4Pin IP20 COB Strip Lights |
| Flexible LED Strip PCB Process | Optimal thickness 0.25mm to 0.35mm / Suitable for IP20 LED strips | Optimal thickness 0.25mm to 0.35mm / Suitable for IP20 LED strips |
